SPECIAL FEATURES:

• Shut off adaptor for under pressure drilling with every type of standard saddle.
• Body high quality epoxy powder coated (fusion bonded), coating thickness DFT min. 250 microns, zero porosity (tested with 3000V), high impact resistance and cross-linkage according to DIN 30677-2 and DIN 3476.
• Complete with integral double O-ring sealing shut-off device for under pressure drilling (hot tapping).
• Threads according to EN 10226.

MATERIALS:

Body:
Ductile iron EN-GJS-400-15 / EN 1563 (former to DIN GGG40)

Shut-off device:
Guides from POM
O-rings from rubber (potable water approved)
Cover from polyamide PA
Bolts from stainless steel A2-70 EN ISO 3506

All metal, rubber, and coatings used have been designed for contact with water for human consumption, pursuant to the terms of Italian Health Ministry decree n° 174, dated 6/4/2004.
